HDC2L - 4 Ton Capacity Dump Trailer
![](https://static.wixstatic.com/media/a7ffa5_a75f74f0c7c04d6fb8d30f6001dbc5c2~mv2.jpg/v1/fill/w_380,h_222,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/a7ffa5_a75f74f0c7c04d6fb8d30f6001dbc5c2~mv2.jpg)
STANDARD SPECIFICATIONS
GVWR: 11,900 lbs.
Empty Weight: 3,900 lbs.
Maximum Payload: 8,000 lbs.
Overall Length: 17'
Deck Length: 12'
Overall Width: 98"
Bed Width: 78"
Bed Floor Height: 30"
Bed Side Height: 27"
Hitch: 2 5/16" Adj. Ball Hitch
Hitch Height: 18-26"
Fenders: Diamond Plate
Axles: (2) Dexter 6K EZ Lube w/ electric brakes
Suspension: Dexter slipper leaf spring
Brakes: 12" x 2" electric self-adjust w/breakaway
Wheels: 16' x 6" silver mod 8-Bolt
Tires: Loadstar 235/80R16 10 ply
Jack Capacity: 7000 lb. with adjustable foot
Main Frame: 6" Channel @ 8.2#
Bed: 10 gauge
Crossmembers: 4x3x3/16" tube & 3" channel
Gate/Doors: Double barn door w/spreader gate
Pump: KTI double acting
Battery: 12-volt deep cycle
Lift Mechanism: 3.5" bore single cylinder
![](https://static.wixstatic.com/media/a7ffa5_e3e536700e3844cc8538dddad1db00f7~mv2.jpg/v1/fill/w_92,h_61,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/a7ffa5_e3e536700e3844cc8538dddad1db00f7~mv2.jpg)
![](https://static.wixstatic.com/media/a7ffa5_0194a26bb2ee4ffb8157bbb30aa83b4c~mv2.jpg/v1/crop/x_0,y_379,w_720,h_425/fill/w_376,h_222,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/a7ffa5_0194a26bb2ee4ffb8157bbb30aa83b4c~mv2.jpg)
OPTIONS
TK - Tarp Kit w/ hand crank
​
OBC - On-board Charger
​
GNB - Gooseneck w/adjustable 2 5/16" ball hitch
​
STM - Spare Tire Mount
​
TTB - Tongue Tool Box (optional hydraulics)
​
5FT - 5' Ramps
​
HSB- Hydraulic Surge Brakes
​
CO - Colors: Black & Yellow
